系统具备测量模块化管理，并通过亚像素图像处理技术来提高测量精度，*小达到1/3~1/5像素(0.005mm)；

The modular system includes a measurement management, and to improve the measurement accuracy by the sub-pixel image processing technology, a minimum of 1/3 ~ 1/5 pixels (0.005mm);

翘曲度测量：对测量物拟定中心轴线，通过伺服马达带动瓶坯的转动，测量瓶坯外壁与中轴线偏移，通过图片处理和软件计算得出瓶坯翘曲度数据；

Warpage measurement: measurement was prepared central axis, driven in rotation by a servo motor preform, the outer wall of the preform measuring axis offset data calculated by the warp preform and image processing software;

壁厚测量：平行光源照射瓶坯，相机分别获取瓶坯内壁与外壁的折射光信息，通过图片处理和软件算法，计算出两束光源的位置信息并计算出壁厚结果；

Wall thickness measurement: parallel light source preforms, preforms cameras respectively acquire the inner and outer walls of the refracted light information and the pictures by the processing software algorithms, to calculate the position information of the two light beams and the thickness calculated result;

卡坯头可根据不同瓶口进行便捷更换，而且配备不同高度的卡坯头来适应获取不同位置的壁厚；

Card blank head can be easily replaced as a different finish, but with a different height adapted to the thickness of the card blank head acquired at different positions;

具备远程控制功能，便于仪器维护；

It includes a remote control function, easy maintenance of the instrument;

测量数据可直接接入客户的数据系统，避免人为的数据抄录，并可一键式数据导出或打印；

Measurement data can be direct access to the customer's data system to avoid artificially reproduced data, and a print button or the data lead;
